Felt Mountain Bike Carbon – Doctrine size 18

Description

Frame: Felt XC, UHC Advanced carbon fiber, MMC with InsideOut construction, full carbon
dropouts, ControlTaper head tube, Kevlar chain watcher, replaceable derailleur hanger,
flat mount disc mounts, BB92, 12 x 148mm Syntace style thru axle, internal derailleur
cable routing
Fork: RockShox Sid RL Debonair with Charger 2, 100mm travel, OneLoc remote, 15 x 110mm
Boost thru axle
Headset: FSA integrated sealed cartridge bearing, No.42ACB-A, 1.125” – 1.5”
Stem: Devox, ±7° rise, Ø31.8mm with Cr-Mo bolts, XS/SM: 60mm, M/L: 70mm, XL: 90mm
Handlebar:
Devox carbon flat top, Ø31.8mm, 8mm rise, 9° sweep, 720mm wide
Grips: Silicone Foam
Shifters: SRAM X01, 1×12
Rear Derailleur: SRAM X01 Eagle, 12-speed
Crankset: SRAM X01 Eagle, 34T, XS/SM: 170mm, MD/LG/XL: 175mm
Chainguide: One Up S3, Low direct top guide
Bottom Bracket: SRAM GXP BB92
Chain: SRAM X01, 12-speed
Freewheel / Cassette: SRAM XG1295, 12-speed, 10-50T
Brake Levers: SRAM Level TLM
Brake (Front): SRAM Level TLM hydraulic disc, 180mm rotor
Brake (Rear): SRAM Level TLM hydraulic disc, 160mm rotor
Saddle: Prologo Kappa RS, T2.0 rails
Seatpost: Devox carbon post, forged head, 15mm offset, Ø27.2, XS/SM: 350mm, MD/LG/XL:
400mm
Seatpost Clamp: Felt single bolt, Ø31.8mm
Rims / Wheelset: DT Swiss M1900 wheelset, tubeless ready, 25mm inner width
Front Hub: DT, 15 x 110mm Boost thru axle, 6-bolt
Rear Hub: DT, XD driver, 12 x 148mm Boost thru axle, 6-bolt
Thru Axles: Rear: Felt leverless 12 x 148 x 166L Syntace style, thread: M12 x 1.0
Tires: Schwalbe Rocket Ron front + Racing Ralph rear Evo, LiteSkin, Addix speed, folding,
tubeless ready, 29 x 2.25”
